Handheld Barcode Scanner ABS-9590

Handheld Barcode Scanner ABS-9590
Handheld Barcode Scanner ABS-9590 Handheld Barcode Scanner ABS-9590
Brand: AOE
Product Code: Handheld Barcode Scanner ABS-9590
Availability: Out Of Stock
Price: Rs6,999
Ex Tax: Rs6,999
Qty:     - OR -   Add to Wish List
Add to Compare

Product Information:

  • ABS-9590 Handheld Barcode Scanner
  • customer setting: Barcode setting mode, easy to operate
  • Scan Depth of field up to 350mm
  • Antiknock design: withstand 1.5M drops
  • Support 20 countries keyboard languages
  • Service life of button reaches up to 50 million times
  • Supporting the RS232, PS2 and USB interface
  • Full independent intellectual property rights
  • Robust design

ABS-9590 Technical Specifications:

PERFORMANCE PARAMETER

  • Light Source: Visible Laser Diode 650nm
  • Scan Pattern: Single Scan
  • Scan Rate: 50 times/second
  • Scan Precision: 4mil
  • Scan Width: 30mm@scan window, 220mm@200mm
  • Scan Depth of field: 0-350mm (0.33mm pcs0.9)
  • Decode Capability: EAN-8, EAN-13, UPC-A, UPC-E,Code 39, Code 128, EAN128,   Codabar, Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, MSI, etc.
  • Tilt: 30
  • Elevation Angle: 65
  • Deflection Angle:  55
  • Support Inferface: RS232, PS2 and USB
  • Print Contrast: 30% UPC/EAN 100%
  • Mention Pattern: Buzzer, Indicator
  • Scan Mode: Manual & continue scanning

MECHANICAL PARAMETER

  • Size: L x W x H: 170mm x 68mm x 98mm
  • Weight: 153g
  • Material: ABS + PC
  • Cable: Standard 2M straight

ELECTRICAL PARAMETER

  • Voltage: 5VDC
  • Operating Current: 85mA    peak current (120 mA )
  • Static Current: 36mA
  • Laser Class: Meet the Grade I National Criteria for Laser Safety
  • EMC: CE & FCC DOC compliance

ENVIRONMENTAL  PARAMETER

  • Operating Temperature:  0°C to  45°C
  • Storage Temperature: -20°C to  60°C
  • Humidity:  5% to 85% relative humidity, non-condensing
  • Light Levels: Daylight, 5000Lux
  • Shock: Designed to withstand 1.5M drops
